ABB   PP836 3BSE042237R1  操作面板 PLC 觸摸屏

ABB   PP836 3BSE042237R1  操作面板 PLC 觸摸屏

ABB   PP836 3BSE042237R1  操作面板 PLC 觸摸屏

品牌

DCS

風速

10km/h

原產地

瑞典

重量

2.4lb

功率

24VDC

頻率

1020Hz

通道

8通道

溫度

1000℃

可售賣地

全國

類型

模塊

型號

PP836

ABB PM802F/ABB PM803F概述：

AC800F控制器主板ABB PM802F/ABB PM803F有6個槽位及1個電源槽位，其中有2個槽位采用快速DMA技術與CPU直接進行高速數據通信，這2個槽位通過插入以太網模件實現控制層基于標準 TCP／IP協議以太網的信息傳遞，剩余4個槽位F1…F4采用中斷方式與CPU及主存儲器進行數據交換，每個模件都可以產生自己的中斷源，強大的中斷控制器及先進的多任務操作系統可以快速響應來自這4個通信模件的中斷信息及迅速與之進行數據交換，同時通過優先級的控制可以實時接收通信模件的錯誤報告信息CPU板數據總線的帶寬為100MB／s，保障來自各種通信模件的大信息量數據快速傳遞到CPU單元進行處理。為了保證數據最大程度的準確率，AC800F CPU單元的主存儲器芯片具有錯誤檢測及修改能力，可以檢查32位數據字的2位錯誤及修改1位錯誤PM803主板提高主存儲器的存儲容量為16MB，實現在AC800F控制器上執行大容量的控制程序，但相應的程序保持設備要更新。

ABB PM802F／ABB PM803F特點：

高效超標量RISC CPU

專用系統總線及控制器冗余連接通信的協處理器

ABB PM802F主存儲器采用靜態RAM，具備電池保持功能當主電源故障恢復后快速啟動

ABB PM803F主存儲器器采用同步動態隨機存儲器(SDRAM)，當主電源故障恢復后可以快速啟動，具備電池保持功能但由于容量較大，保持時間比ABB PM802F短

主存儲器具有自動錯誤檢查及修改能力(EDC單元)，可以檢查2位錯誤及修改1位錯誤的數據字

硬件組態及診測數據存儲在16K位EEPROM

脈沖串快速擦除EPROM，用于快速ROM操作，這部分主要用于存儲控制器固化程序，保證軟件升級無需更換EPROM芯片

RS232串行接口，用于控制器診測服務和無線時鐘信號接口，該接口為標準9針D型接口，位于所有類型的電源模件上，同時支持冗余控制器模式的操作

所有類型的電源模件上還設置控制器基本操作的開關，如：運行/停止工作開關，控制器復位開關，冗余手動切換開關

所有類型的電源模件上還設置控制器狀態的LED顯示

E1及E2槽具備冗余電池供電功能提供電池能量自動監控/報警及自動切換保持RAM數據功能

CPU主板溫度監控，周期性溫度測量

累積控制器正常與高溫運行時間

所有現場總線模件可以在系統運行時，帶電進行插拔

由于使用IC接口，F(xiàn)1…F4槽總線模件可以自動識別和重新裝載組態數據，實現既插既用功能

來自模件的數據錯誤信號識別及處理

每種總線模件產生多達4個不同中斷源

每個模件預留地址域8MB用于內存訪問8MB用于I／O訪問

操作溫度范圍0…60~C，無需強制冷卻，請注意這是指控制器為整體封裝時的指標

內部工作電壓監控

獨立的”watchdog”模塊用于保護操作系統的死鎖現象

電池保持系統實時時鐘

電源故障信號報警
